Advanced Logic Technology WellCAD v5.5 Build 427 (x64)

[filwodesseri]

Advanced Logic Technology WellCAD v5.5 Build 427 (x64)



x64 | File Size: 276 MB

Description
Mount Sopris offers WellCAD log acquisition and processing software, the most intuitive and comprehensive user interface in the industry. Combining excellent display, editing and analysis capabilities, WellCAD has become the standard log composite software in mining, natural resource, geotechnical, and other communities. WellCAD is a trademark of Mount Sopris partner, Advanced Logic Technology.

Rich Graphical Display
-Fully graphical driven standard Windows* software
-Real-time data display generated from the depth / time based information held in the data repository
-Display of curves, patterns, symbols, text, formation markers, image data, photographs,.
-Comprehensive sets of formatting styles (point, bar, curve style, color, thickness, fonts, shading,.)
-Editor for custom symbols, patterns, header & trailer design
-3D Borehole Display

Comprehensive Interpretation Tools
-Common Data Processing Tools : resampling, filtering, single-, block- or multi curve statistics, equation editor,.
-Specialized Workspaces for Image & Structure Interpretation, FWS data, core description, multi-well correlation,.
-Cased Hole Interpretation Workspace (available in 2016)
-Cross plotting workspace and chart log
-Application Programming Interface for batch processing scripts or advanced algorithm development

Intuitive Data Management
-Choose from 28 different data container types to host single point, interval or array data
-New intuitive user interface to manage data and properties
-Powerful templates for automatic plot formatting
-Alias tables for mnemonic management and standardization
-Automatic audit trail of changes made to each data container

Mobility
-WellCAD works on PCs, laptops and tablets with Windows OS (64bit compatible, supported by Windows XP, Vista, 7, 8, 8.1 and 10)
-Completely portable through hardlock protection or server license borrowing
-Does not require a connection to a database system

Data presentation
-Display of curves, patterns (e.g. lithology), symbols (e.g. fossils), text, formation marker, hierarchical stratigraphic columns, image data (e.g. FMI, ATV, OTV), photographs, operational symbols (e.g. DSTs, RFTs, Mud Data, Survey Data, etc.), .
-An unlimited number of data containers, of which 28 different types exist to host single point (continuous and discontinuous), interval or array data, can be freely positioned on the workspace and combined for complex WYSIWYG plot formatting.
-Audit trail for each data container and processing step (i.e. Log History).
-No restriction to number of tracks or number of curves to be plotted or superimposed.
-Comprehensive sets of formatting styles are available for each data container type - pen type, pen thickness, pen color, fonts, shading, curve style (e.g. point-to-point, step or bar) and many more.
-Scale and appearance of vertical grids can be customized using individual classification schemes (e.g. Wenthworth scale, Phi scale).
-Depth may be referenced to MD, TVD, TVDSS or any other depth (or date & time) system due to capabilities of non linear depth matching. Support of depth and elevation display.
-Libraries of customizable and scaleable patterns and symbols (e.g. lithology, physical structure, fossils, pore types, .) are provided. The freely distributed LithCAD application allows design and import of new patterns and symbols.

System Requirements
OS:Windows Win7, Win8 and Win10 (x64)
